Single Axle
Multi-Purpose Utility Trailers WT SERIES GVWR 2990#
Size & Model
| 5'X9' | WT95-24FMR |
| 5'X11' | WT115-24FMR |
| 6'X10' | WT106-24FMR |
| 6'X12' | WT126-24FMR |
| 6'10"X10' | WT10610-24FMR |
| 6'10"X12' | WT12610-24FMR |
| 6'10"X14' | WT14610-24FMR |
STANDARD FEATURES
| AXLES | DEXTER 3500LB AXLE |
| BRAKE | N/A |
| COUPLER | 2" BULLDOG STYLE COUPLER |
| CROSS MEMBER | L2X2X3/16" ON 20"C |
| FENDERS | 1/8" HEAVY DUTY DIAMOND PLATE FENDERS |
| FLOOR | 2"X6" TREATED WOOD FLOOR |
| FRAME | L2X2X3/16" ANGLE |
| FRAME NECK | N/A |
| JACK | 2000LB TOP WIND JACK WITH SAND FOOT |
| LIGHTS | LED LIGHTS ENCLOSED STEEL BOXES |
| MOUNT | SPARE TIRE MOUNT |
| PAINT | * PPG URETHANE 4:1 PAINT |
| RAILING | 2SQ11GA. SQUARE TUBE TOP RAIL (16" TALL) |
| RAMP | 48" BI-FOLD REAR RAMP GATE |
| SAFETY | DOT REFLECTIVE TAPE/ 1/4" SAFETY CHAINS |
| TIE DOWN | 3/8" ROD CORNER TIE DOWNS |
| TIRES | (2)NEW 205-75-15D 6-PLY |
| TONGUE | C3X3.5 CHANNEL WRAP TONGUE |
| WHEELS | 15" SILVER MOD WHEELS (6-LUG) |
| WIRING | SEALED HARNESS RAN THROUGH FRAME |
OPTIONAL FEATURES
| DOUBLE BARRELL SPRING ASSIST | |
| CASTER WHEEL FOR JACK | |
| SWIVEL JACK | |
| TONGUE TOOLBOX WITH LOCK | |
| 60" WIDE X 48" LONG SIDE GATE (14' TRAILER ROD) | |
| 48" SPRING ASSIST NON BI-FOLD (UPGRADE) | |
| 48" NON BI-FOLD REAR RAMP (UPGRADE) | |
| BOARD CHANNELS | |
| 1/8" DIAMOND PLATE FLOOR | |
| 3/8" D-RINGS (specify location) | |
| 14 GA. SOLID SMOOTH SIDES | |
| CUTOUTS FOR STAKE POCKETS | |
| EXPANDED METAL SIDES |
